A9F04104 Schneider iC60H Miniature Circuit Breaker

Description A9F04104 Schneider iC60H Miniature Circuit Breaker Product Dimensions： Product Description (Detailed Explanation) The Acti9 iC60H series is part of Schneider Electric’s premier modular system for low-voltage electrical installations. The A9F04104 is a single-pole (1P) breaker with a 4 Amp rating and a Curve C tripping characteristic. It features the exclusive VisiSafe and VisiTrip technologies. VisiSafe provides a visible green indicator to guarantee the downstream circuit is safe for maintenance, while VisiTrip allows for fast identification of a fault by highlighting the tripped breaker with a red mechanical indicator on the front face. Product Parameters (Technical Specifications) Parameter Category Specification Product Range Acti9 iC60 Pole Configuration 1P (Single Pole) Rated Current ($I_n$) 4 A Curve Code C (Tripping between $5 \times I_n$ and $10 \times I_n$) Breaking Capacity 10,000 A (10 kA) Icn at 230V AC (EN 60898-1) Breaking Capacity (Industrial) 15 kA Icu at 220…240V AC (EN 60947-2) Rated Operational Voltage 230 V AC 50/60 Hz Insulation Voltage ($U_i$) 500 V AC IP Degree of Protection IP20 (Device), IP40 (Modular Enclosure) Mounting Mode DIN Rail (Toggle operated) Product Advantages (Key Benefits) Fast Fault Identification (VisiTrip): Reduces downtime by allowing maintenance personnel to quickly spot which breaker has tripped due to an electrical fault. Maximum Safety (VisiSafe): Ensures that the contacts are physically separated and isolated even in harsh environments or if the toggle is forced. High Breaking Capacity: Rated for up to 15 kA (industrial), making it suitable for demanding applications where high fault currents may occur. Eco-Friendly: Fully compliant with RoHS and REACH standards, ensuring minimal environmental impact. Double Clip Mounting: Features specialized mounting clips that allow the breaker to be removed from a DIN rail without disconnecting the entire row of busbars. Precautions (Important Notes) Curve Selection: Ensure that a “Curve C” breaker is appropriate for your load. Curve C is suitable for resistive and slightly inductive loads; for high-inrush motors, a Curve D might be required. Terminal Torque: Always tighten the connection terminals to the manufacturer’s specified torque (2 N·m for this model) to prevent overheating or arcing at the contact points. Environment: While rated for industrial use, if installed in very dusty or humid environments, the breaker should be housed within an IP65 rated enclosure. Polarity: For DC applications, pay close attention to the polarity markings if the specific variant allows for DC usage (though this A9F04104 is primarily AC rated). Product Applications (Typical Use Cases) Industrial Control Panels: Protecting small control circuits, PLC power supplies, and sensor loops. Commercial Buildings: Circuit protection for lighting systems and HVAC control units. OEM Machinery: Used by machine builders to protect small motors, heaters, or solenoids. IT Infrastructure: Power distribution for server racks and telecommunications equipment requiring precise 4A protection. Tertiary Sector: Protection of socket outlets or specialized laboratory equipment in hospitals and schools. Shipping Port: Xiamen, China Payment: Bank of Chicago, Bank of Singapore Express cooperation: fedex, DHL, UPS and your express account Service: Professional Sales provides 24 hours /7 days online service Please make an inquiry for more models： SCHNEIDER 140CPU31110C SCHNEIDER 140NRP95400 SCHNEIDER 140NOM25200C SCHNEIDER 140CPU43412AC SCHNEIDER 140SDI95300S SCHNEIDER 140NOM21200C SCHNEIDER 140CPU43412U SCHNEIDER 140SDO95300S SCHNEIDER 140NOM21100C SCHNEIDER 140CPU43412UC SCHNEIDER TSXP57303AM SCHNEIDER 140NOE77111C SCHNEIDER 140CPU53414BC SCHNEIDER 416NHM30032A SCHNEIDER 140NOE77101C SCHNEIDER 140CPU65260C SCHNEIDER 416NHM30030A SCHNEIDER 140NOC78100C SCHNEIDER 140CPU65160C SCHNEIDER LC1D09M7C SCHNEIDER 140NOC78100 SCHNEIDER 140CHS11000C SCHNEIDER 140AC013000 SCHNEIDER 140NOC78000C SCHNEIDER 140CHS21000C SCHNEIDER 140CPS12400R SCHNEIDER 140HLI34000C SCHNEIDER BMXDDI1602 SCHNEIDER 140NOM211OO SCHNEIDER 140ESI06210C SCHNEIDER BMXDDO1602 SCHNEIDER 140NWM10000 SCHNEIDER 140ERT85420C SCHNEIDER BMXAMI0810 SCHNEIDER 140XCP90000C SCHNEIDER 140EIA92100C SCHNEIDER BMXAMO0802 SCHNEIDER 140XBP01600C SCHNEIDER 140EHC20200C SCHNEIDER BMH2052P11A2A SCHNEIDER 140XBP01000C SCHNEIDER 140EHC10500C SCHNEIDER BMXDAO1605 SCHNEIDER 140XBP00600C SCHNEIDER 140DVO85300C SCHNEIDER BMXCPS3020 SCHNEIDER 140XBP00400C SCHNEIDER 140DSI35300C SCHNEIDER BMXDDO6402K SCHNEIDER 140XBP00300C SCHNEIDER 140DRC83000C SCHNEIDER BMXP342020H SCHNEIDER 140XBE10000C SCHNEIDER 140DRA84000C SCHNEIDER BMXEHC0800 SCHNEIDER 140NRP95400C SCHNEIDER 140DDO88500C SCHNEIDER BMXAMO0410 SCHNEIDER 140NRP95401C SCHNEIDER 140DDO84300C SCHNEIDER BMXXBP1200 SCHNEIDER 140NRP31201C SCHNEIDER 140DDO35310C SCHNEIDER 140CRA21120 SCHNEIDER 140NRP31201 SCHNEIDER 140DDO35301C SCHNEIDER 140ERT85420 SCHNEIDER 140NRP31200C SCHNEIDER 140DDO15310C SCHNEIDER 140N0E77100 SCHNEIDER 140NRP31200 SCHNEIDER 140DDO35300C SCHNEIDER 140NOC78000 SCHNEIDER 140NOP85000 SCHNEIDER 140DDM69000C
