OpenSprinkler (OS) Smart Irrigation Computer

�� Version comparison: Which OpenSprinkler version is the right one? → To the large comparison table (Original vs. Shop vs. Pro) Update: The new AC powered OpenSprinkler v3.4 is now available – click hereto find out more about this new version. Update 2: The new DC powered OpenSprinkler v3.4 is now also available – click hereto find out more about this new version. OpenSprinkler is a Open source, Web-based, intelligent irrigation computer (sprinkler controller) for lawn and plant watering, drip irrigation, farm irrigation, greenhouses, hydroponics etc. How does it work? This is how it works! DC or AC version – which is better? Do you also need housings and accessories? Then click here! Read the current test here! Features: Time-controlled control of 24VAC valves (AC DC versions), 12VDC valves (DC version), self-holding DC solenoid valves (latch version). Free Android and IOS app Web interface for access from the PC Dynamic irrigation control by retrieving the weather report (internet connection required) Up to 8 valves in the standard version, additional 16 valves included Zone expander (max 72 valves) possible Two universal connections for rain sensor, water meter or switch Control of up to two main water connection valves Remote access via OpenThings Cloud (OTC) – Control your OpenSprinkler from anywhere! Running irrigation programs in parallel or serially (simultaneously or one after the other). MQTT status and IFTTT interface RF interface (radio module with 433MHz interface). Additional product RFToy You can find even more features in the FAQ experience. Control OpenSprinkler from anywhere? Activate OTC! Test the program interface? Create programs? Here is the demo: http://demo.OpenSprinkler.com Password is “opendoor” version AC DC 3.3 DC 3.4 Latch Hardware revision 3.3 / 3.4 3.3 3.4 3.3 Power supply? 24VAC 7.5VDC-12VDC USB-C 7.5VDC-12VDC POE not possible via adapter not possible via adapter WiFi Yes Yes Yes Yes Ethernet Option (W5500 100MBit) Option (W5500 100MBit) Option (W5500 100MBit) Option (W5500 100MBit) Solenoid valves 24VAC, no self-holding valves 24VAC 12VDC, no self-holding valves 24VDC ball valves* 24VAC 12VDC, no self-holding valves 24VDC ball valves* 9-12V self-holding valves (impulse coils) Relay controllable Yes, 24VAC Yes, 3-32VDC semiconductor relay Yes, 3-32VDC semiconductor relay No Standard power supply (optional) 24VAC 1.5A 7.5VDC 2.93A USB-C 7.5VDC 2.93A DIN rail power supply (optional) 24VAC 12VDC not possible 12VDC Power supply: 24V AC model, 5-12V DC model                        * Additional 24VDC power supply required AC power supply: Calculate the power using the following formula. To do this, you need to know the current consumption of the solenoid valves. OpenSprinkler has a power consumption of approximately 2.2W = approx. 0.1A. A Rain-Bild solenoid valve has a maximum current of approximately 0.3A I.e. with 4 solenoid valves AT THE SAME TIME you have 4x 0.3A 0.1A = 1.3 A inrush current, the next larger power supply with 1.5A should be used. We have various power supplies in the shop. If you only operate one or two solenoid valves at the same time, you have 2×0.3A 0.1A = 0.7A, a 1A power supply is sufficient. Even if you have 20 solenoid valves but only activate 2 at the same time, that is enough. Note: This is just an example calculation! Please note the technical data of the solenoid valve manufacturer! Note: Total maximum current=3A (fuse) Note: Only applies to OpenSprinkler AC. You can find other suitable power supplies here: Plug-in power supplies AC, Plug-in power supplies DC, DIN rail power supplies AC and DIN rail power supplies DC Never connect more than ONE solenoid valve to ONE OpenSprinkler output! OpenSprinkler can switch several outputs at the same time, so it is not necessary to combine several valves. An AC output can deliver up to 800mA current. If that is not enough, then you should operate the outputs via relays. Version with plastic housing Hardware revision 3.3 and 3.4 supports the W5500 network module with 100MBit interface Temperature working range: -30 to 70 degrees Celsius Note: Product from the USA, delivery times longer if out of stock System requirements Further information (manual, circuit diagram) here: Manual and downloads
